Alfa Laval Gasketed Plate & Frame Heat Exchangers
Next-Gen Features
Unique features to improve process efficiency and reliability.
Efficiency
CurveFlow™ distribution area
⦁ Improves media flow and minimizes the risk of fouling
⦁ Fully utilizes available surface area
⦁ Provides perfect distribution inside channel, unit stays clean longer
OmegaPort™ noncircular port holes
⦁ Enhances media flow and thermal efficiency
⦁ Avoids short cuts in plate pack
⦁ Pressure drop better utilized for heat transfer
Offset Gasket Groove
Ensures plate utilization for maximum heat transfer efficiency
FlexFlow™ plate design
⦁ Improves thermal efficiency and optimizes pressure drop utilization
⦁ Perfect for applications with unequal flows
⦁ Both channels stay clean longer
Reliability
Five-point alignment
Ensures reliable plate positioning and easy service of large units
SteerLock™ plate alignment
Ensures reliable plate positioning and easy service
PowerArc™ plate pattern divider
Improves plate rigidity for longer lifetime
RefTight™ sealing system
High-performance gasket sealing for high-pressure duties
Serviceability
ClipGrip™ gasket attachment
Ensures perfect seal and trouble-free maintenance
T-Bar Roller
Provides a lower unit that is easy to service
Bearing boxes
Guarantees an easy-to-open unit for smoother, more efficient maintenance
Compact frame
Facilitates maintenance and minimizes service area requirement
